PILOT PMAC201HW Modbus 3 phase 4 wire energy meter connection

FOB Reference Price:Get Latest Price
$0.0001 / Unit | 1 Unit/Units (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
PILOT
Model Number:
PMAC201HW
Display Type:
Digital Only
Phase:
12 phase
Measuring Energy Range:
0~ 99,999,999.9 kWh
Accuracy Class:
0.5%
Output Voltage:
0~570V (L-L)
Operating Temperature:
-20℃~ +55 ℃
Dimensions:
110*75*80.1mm
Current:
CT primary: Rated input: 20A, Max. input: 100A
Voltage:
Rated input: 220/380V
Frequency:
50/ 60Hz
Overload:
120% of rated voltage, continuously
Connection mode:
3 phase 4 wires or 3 phase 3 wires
Power supply:
18~72V DC
Communication:
RS485 serial, support Modbus-RTU
Baud rate::
1200, 2400, 4800, 9600, 19200 bps
Storage temperature::
-40℃~ +70 ℃
Humidity::
5%~95% non-condensing
Supply Ability
Supply Ability:
3000 Unit/Units per Month
Packaging & Delivery
Packaging Details
2pcs in one carton
Port
Zhuhai Port
Lead Time :
Shipped in 2 days after payment

PILOT PMAC201HW Modbus 3 phase 4 wire energy meter connection






Product Description



PMAC201HW is a Din Rail Mounted intelligent multi-function power monitor. It is specifically designed to measure the power consumption of circuit within an electrical distribution board. It provides a cost effective solution to understanding energy consumption within your building. A quick and easy installtion, the PMAC201HW will mesure volts, amps, watts, active power, reactive power and frequency.







Features





1. Suit for voltage under 330V (L-N)/570V(L-L) (direct)





2. Used for 4*3 phase or 12*1 phase circuit AC measuring





3. Auto-distinguish mix connection of three phase and single phase



4. different circuit can be set to different current



5. Ture-RMS measuring parameter for U, I, P, Q, S, PF, F, kWh(Imp. & Exp.), kvarh (Imp. & Exp.), Demand, Max./Min. value (P)



6.  TOU, 4 tariffs, 8 time period in 24 hours



7.  Memory data per 15 min., Max. Memory 40days data



8.  Record SOE (Event log) and modify setting event



9.  Support 100mA rated current input, CT primary up to 5000A



10. LED light for pulse output, Run and communication



11. Din Rail Mounted, Provide MODBUS communication protocol.





Technical specification











Dimension











Current transformer









Power supply converter







Typical application



1. In Telecommunication BTS















2. In Smart Building system





     1 PMAC201HW = 12 single phase energy meter = 4 three phase energy meter  !!!
